Howard Energy Corporation
has concluded that the future of the Illinois Basin lies in its deep potential. Consequently, an investigation has been conducted into the feasibility of exploring this huge untapped resource. It has long been a common belief in the industry that these deeper reserves exist, however the methods and procedures used in the past have been unsuccessful.

Consideration was given as to what technological advances currently exist that would increase the probability of a successful test. It was determined that the first step would be to run an aeromagnetic survey over a large area (250 square miles) of the basin to identify prospective areas with significant basement structure. These areas would then be subjected to seismic and soil gas analysis.

It is believed that an overlap of these three investigative tools will provide the best possible prospect. Howard Energy Corp. has recently completed this procedure and has identified an area in Perry County, Illinois which is geographically located approximately 9 miles west and north of Pinckneyville, Illinois. An acreage block of about 1900 acres has been assembled for the purpose of drilling a wildcat well. The text of the above reports will outline the logic for this exciting venture.


Illinois Basin Geological

The Illinois Basin, which covers approximately 53,000 square miles, is a broad elliptical basin covering most of Illinois, southwestern Indiana, and western Kentucky. Its main axis trends from the northwest to the southeast. It is basically bland structurally with the exception of the LaSalle Anticline which trends to the southeast across a major portion of the basin and some fault systems, which are primarily located in the southeastern part of Illinois.

The Illinois Basin is located in the central lowland province, which also included north central Texas, central Oklahoma, eastern Kansas, and Michigan. The sub surface geology and paleo-environment of the province appear to be correlative throughout with commercial production in the deeper intervals in other parts of the province that are not currently being produced in the Illinois Basin.
TOP


Production History

The initial production from the Illinois Basin came from the Trenton field, which was discovered in 1884 in central Indiana. It contained approximately one billion barrels of oil and produced a total of 105 million barrels of oil under primary means with the peak period between 1900 and 1904. The field also produced approximately one trillion cubic feet of gas. Further development in the early 1900's took place in the Main consolidated and Lawrence field in Illinois and the Oakland City and Princeton fields in Indiana. Most of this production was in the range of 1000 feet.

The next boom took place in 1938 when seismic information was utilized in the discovery of Dale, Salem, Clay City and Loudon fields. In 1940, Illinois was the 4th largest producing state in the nation. Production in the basin steadily declined until the mid 1950's when waterflooding was initiated along with the discovery of the hydraulic fracturing. Exploration since that time has been primarily in the limestone intervals below the St. Genevieve and through the Warsaw. As of this date the Illinois Basin has produced approximately 4.2 billion barrels of reserves.
TOP


Prospect Logic

To date the number of penetrations in the deeper horizons has been very limited in the Illinois Basin (less than 25 that penetrated the pre cambrian strata). Almost all of the deep wells were drilled in the heart of a large shallow structure that produced significant volumes of reserves. It is conceivable that this method would be inappropriate to discover economic reserves in the lower strata. Geologically it is evident that the zones in question are correlative to those, which produced in other basins in the United States.

The fact that source beds are available is proven with the free oil found in Union Oil Company's Cisne # 1 located in northern Wayne County, which is almost the center of the basin. This well recovered ten feet of free oil from a drill stem test of the Shakopee dolomite at a depth of approximately 7800 feet. Having fulfilled the requirements of an oil source, consideration has to be given as to the trapping mechanism available. The areomagnetic and seismic surveys have identified this prospect to have sufficient structural qualities to warrant the proposed test.
TOP


Potential Oil & Gas Bearing Reservoirs

Trenton Limestone (Upper Ordovician 3500' - 3600')
This will be the first zone of interest for this test. Based on the seismic data we will be on the flank of a significant nosing for this zone. The Salem field produced about 5 million barrels of oil from the Trenton. (This zone should be about 100 feet thick in our prospect.) Porosity, fractures and localized dolomitization are possible here to make this zone productive.

St. Peter Sandstone (Middle Ordovician 4400' - 4600')
Commonly referred to as the St. Peter McLish Oil Creek Sandstone (Simpson Group) - Kansas, Oklahoma, Kentucky. The St. Peter is well-rounded poorly cemented sandstone that is deposited across the Illinois Basin. It can be expected to have 14-16% porosity and permeability of 200 md or better. There have been slight shows of oil and gas in some of the limited penetrations.

Knox Dolomite Megagroup (Lower Ordovician - Upper Cambridge 4600' - 6700').
This is of primary interest and correlates to the Arbuckle and Ellenberger in Texas, Oklahoma and Kansas. It is also similar to the Prairie du Chien in Michigan. The Knox was also of major interest in the eastern overthrust belt through eastern Kentucky and West Virginia. South central Kentucky has had significant production from this reservoir. In an AAPG study the # 1 Cuppy well drilled in Hamilton Page 6 County, Illinois yielded about 40 ppm organic material from the benzene extraction in this zone.

Eau Claire Formation (Middle Cambrian 6100' - 6700')
This is the lower most section of the Knox megagroup and equates to the Bonneterre formation in Kansas. This zone should be primarily dolomite with sandy oolitic lime intervals. Based on the seismic data we have a significant structure with a possible fault to the west. Two wells the Cisne # 1 Community in Wayne County, Illinois and Cuppy # 1 in Hamilton County, Illinois had porosities of 10-20% with gas shows. A drill stem test on the Cisne # 1 Community yielded gas cut saltwater. The Cuppy # 1 had organic carbon content of 1.5%.

Mt. Simon Sandstone (Lower Cambrian 6800' - 6950')
This formation is also known as the Reagan Sandstone in Oklahoma and Kansas is the deepest zone to look at however, this zone may or may not be present at this location but does have good permeability and porosity at shallower depths when found where it is used for gas storage in northern Illinois. In all over 3000 feet of potential reservoir rock will be exposed with this test.
TOP


Technology Utilization

Although previous attempts to explore for deep oil and gas in the Illinois Basin have failed, no known attempt was made utilizing these specific technology's to identify a prospect. A review of the services available resulted in a plan to integrate three separate prospecting tools, which were aeromagnetic surveys, seismic surveys, and soil gas analysis. It was concluded that the project would be initiated by running an aeromagnetic survey over a large section of the basin.

After identifying a prospective area, seismic and soil gas analysis would then be run to confirm the prospect. It is felt that a positive test from these three procedures will result in the most favorable prospect available. The results of the surveys conducted on this project are provided for your review in the appendix of this report.
TOP


Conclusions and Recommendations

For the past 100 years the major oil companies have produced the bulk of the reserves in the Illinois Basin. They have now all gone in search of the more lucrative areas in foreign lands, many using the same tools that were used for this test. During their tenure they expended a very small portion of their resources in exploring the lower two thirds of the sediment in the basin. It is believed that this indifference has now provided the independent operators with one of their greatest potentials.

While it is apparent that the major oil companies endeavors in deep exploration was unsuccessful the possibility of reserves being available is still good. Should the approach with these technology's prove itself, there would be an enormous opportunity for those in the initial venture to expand its use. It is therefore recommended that the subject test be commenced at the earliest possible date.
